wire decking technical features:

1. Flared wire decking is designed to use on beams without insert ot step, mainly used on box beam.

2. Welded with U channels under wire decking to ensure the load capacity.

The end of the channel is open and flared, enabling it to sit between the beam and decking.

3. Wire decking is variety in wire diameter, mesh size and channel numbers, all are selected based on the work load requriement.

Wire diameter: 4.0-6.0mm;

Mesh size: 100*50, 100*25, 50*50, 50*25, among these, 100*50(4"*2") is the most popular;

Flared channels: 2-6 channels.

4. Surface treatment: galvanization or powder coating, beautiful, antirust, corrosion resistant and oxidation resistant.

wire decking advantages:

1. Wire mesh structure allows easy identification of goods and prevents dirt from accumulating on the shelving.

2. Effect solution to enhance the versatility and safety of storage racking.

3. Meet fireproof requirement and can also helpe to reduce the insurance rates.

4. Durable, light in weight, easy to handle and maintain, widely used in American, European, Australia market.

We have three style wire decking : Flared wire decking, drop in wire decking, channel wire decking.

Flared wire decking

Drop in wire decking

Channel wire decking

Item No.	Specification(mm)			Wire dia.(mm)	Mesh (mm)	Load capacity (kg)
Item No.	L	W	H	Wire dia.(mm)	Mesh (mm)	Load capacity (kg)
BG01	1350	1200	50	6.4	50*50	500-1000
BG02	1350	1000	50	6.0	50*50	500-1000
BG03	1200	1000	40/50	5.5	50*50	500-100
BG04	1150	1000	40/50	5.5	50*100	400-800
BG05	1000	1000	30/40	5.0	50*100	300-600
BG06	900	1000	30/40	5.0	50*100	300-600
Other specification can be customized
